    Product Details:

    Place of Origin: China
    Brand Name: Limplus
    Certification: CE
    Model Number: LS-30T

    Payment & Shipping Terms:

    Minimum Order Quantity: 1set
    Packaging Details: export wooden case
    Delivery Time: 7~10 working days
    Payment Terms: T/T, Western Union, MoneyGram, Paypal
    Supply Ability: 500sets / month
    Contact Now
    Detailed Product Description
    Ultrasonic Power: 1500w Transducers: 30pcs
    Transducer Type: Piezoelectric Warranty Time: 1 Year
    High Light:

    waterproof ultrasonic transducer

    ,

    submersible ultrasonic transducer

    Limplus Ultrasonic Wave Cavitation Piezoelectric Immersible Ultrasonic Transducers System 1500W



    Ultrasonic cleaning has been used as an industrial cleaning process for many years. Limplus ultrasonic cleaners adopt powerful transducer with excellent installing technology to improve how ultrasonic works and get better cleaning performance. The cleaning power comes from the cavitation produced by the ultrasonic transducers that attack the parts where we cannot touch, see or feel. Our ultrasonic cleaner are employee and environmentally friendly, saving labor cost and increasing profits.



    Details of LS-30T:

    Transducer box size: 550*420*100mm

    Ultrasonic power: 0~1500W

    Ultrasonic frequency: 28khz/ 40khz

    Material: SUS304 / SUS316L

    Surface handle: Hard-Cr plating

    Transducer numbers: 30pcs

    Cable leadout method: Rigid or flexible



    Features:

    1. Box size can be customized.

    2. Varies cable leadout method

    3. Hard Cr plating treatment for transducer box.

    4. Multi frequency is also available.

    5. BLT type transducer.



    Limplus ultrasonic transducers advantages:

    1.  Adopting High-Q transducer and adhesive bonding technology from Germany enhance the power of ultrasonic output frequency.

    2.  Adoption of international state-of-the-art technology incorporating with unique bonding technology; Ensuring ultrasonic power, powerful output, never dropping vibrator;

    3. Remove all components for next operation step.

    4. 1 year warranty.

    5. Engineers have more than 10 years experiences in ultrasonic field.



    Transducer box system specification:

    Model Unit Size (mm) Ultrasonic Power(W) Frequency(kHz) Transducers(pcs) Material Voltage
    LS-06T 280*180*100 0~300 28/40 6 SUS304/SUS316L AC 110V/230V, 1phase
    LS-12T 360*250*100 0~600 28/40 12 SUS304/SUS316L AC 110V/230V, 1phase
    LS-18T 410*300*100 0~900 28/40 18 SUS304/SUS316L AC 110V/230V, 1phase
    LS-24T 500*350*100 0~1200 28/40 24 SUS304/SUS316L AC 110V/230V, 1phase
    LS-30T 550*420*100 0~1500 28/40 30 SUS304/SUS316L AC 110V/230V, 1phase
    LS-36T 620*500*100 0~1800 28/40 36 SUS304/SUS316L

    AC 110V/230V, 1phase

    LS-48T 750*600*100 0~2400 28/40 48 SUS304/SUS316L

    AC 110V/230V,

    1phase



    FAQ:

    Q.: What are the advantages of ultrasonic technology over traditional cleaning methods?

    A.: Minimize the use of manual labor

    Make cleaning and degreasing without the use of organic solvents

    Clean hard to reach areas of products and remove all types of dirt

    Shorten the processes such as extraction, dispersion, purification, chemical reactions

    Eliminates costly mechanical and chemical cleaning of heat exchangers



    Q.: Which ultrasonic frequency is better for my parts?

    A.: Frequency is suggested based on pollutants in the objects.

    28kHz frequency is stronger, better for car/motor/truck/vessel parts clean(remove oils, grease, pastes, etc. )

    40kHz is better for pcb boards, electronic parts, etc.

    Higher precision goods, higher frequency.



    Q: How do I get the best out of my ultrasonic cleaner?

    For best results, ensure the component being cleaned is fully submerged in a suitable cleaning fluid and not touching the tank to allow maximum cavitations.



    Please refer below picture and choose the convenient cable leadout method according to your tank.
